00421 Interlock Ferrule For DIN20023 4SH Hose

Description Of Products:
1. Raw Material: Carbon Steel & Stainless Steel available
2. Standard Plating: Trivalent Zinc Plating ( Cr3 / Chrome Free ), Silver & Yellow
3. Salt Spray Test: > 72 Hours ( If customer have higher requirement, we can also do with 200 Hours )
4. Packing: Products are protected with the plastic caps and then packed in carbon box.
5. OEM Service: Available. Customer only need to provide the product drawing or samples.
6. Sample. Please contact our sales person for the free sample.

Get A Quote

PREV：00500 Ferrule For SAE100R5 Hose
NEXT：00621 Interlock Ferrule For GB/T 10544 R13 / SAE 100 R13 / EN856 R13 Hose

Specification
Contact Us

PART NO.	HOSE BORE DN	HOSE BORE DASH	DIMENSIONS L
PART NO.	HOSE BORE DN	HOSE BORE DASH	DIMENSIONS L
00421-20	32	20	88
00421-24	40	24	102
00421-32	50	32	108
Note: When stripping the inner rubber layer from 4SH-12 and 4SH-16 hoses, use the 00621-12 and 00621-12 sleeves respectively.
