20611 METRIC FEMALE 60° CONE

1. Raw Material: Carbon Steel & Stainless Steel available
2. Standard Plating: Trivalent Zinc Plating ( Cr3 / Chrome Free ), Silver & Yellow
3. Salt Spray Test: >72 Hours ( If customer have higher requirement, we can also do with 200 Hours )
4. Packing: Products are protected with the plastic caps and then packed in carbon box.
5. OEM Service: Available. Customers only need to provide the product drawing or samples.
6. Sample: Free sample.

Get A Quote

PREV：10611 Metric Male Double Use For 60°Cone Seat Or Bonded Seal
NEXT：20791 90° GB Metric Female 74° Cone Seat

Specification
Contact Us

PART NO.	THREAD E	HOSE BORE		DIMENSIONS
		DN	DASH	A	C	S2
20611-14-04T	M14X1.5	6	04	18	5.5	19
20611-16-05T	M16X1.5	8	05	18.5	5.5	22
20611-16-06	M16X1.5	10	06	19	5.5	22
20611-18-06T	M18X1.5	10	06	20	5.5	24
20611-20-08	M20X1.5	13	08	22	6.5	27
20611-22-08T	M22X1.5	13	08	22.5	6	27
20611-24-10	M24X1.5	16	10	24.5	6.5	30
20611-26-10T	M26X1.5	16	10	24.5	6	32
20611-27-10T	M27X2	16	10	23.5	6	32
20611-30-12	M30X2	19	12	26.5	6	36
20611-36-16T	M36X2	25	16	30	6.5	41
20611-39-16T	M39X2	25	16	30	6.5	46
20611-45-20T	M45X2	32	20	31	8.5	55
20611-52-24T	M52X2	38	24	32	10	60
Note: 1. For use with braided hoses. 2. If use with spiral hoses, hose fitting series number is 20612-xx-xx.
