50091-RW 90° Metric Standpipe Straight DIN 2353

1. Raw Material: Carbon Steel & Stainless Steel available
2. Standard Plating: Trivalent Zinc Plating ( Cr3 / Chrome Free ), Silver & Yellow
3. Salt Spray Test: > 72 Hours ( If customer have higher requirement, we can also do with 200 Hours )
4. Packing: Products are protected with the plastic caps and then packed in carbon box.
5. OEM Service: Available. Customer only need to provide the product drawing or samples.
6. Sample: Please contact our sales person for the free sample.

Get A Quote

Specification
Contact Us

PART NO.	TUBE O.D.	HOSE BORE DN	HOSE BORE DASH	DIMENSIONS A	DIMENSIONS C	DIMENSIONS H	NOTE
50091-06-03RW	6	05	03	26.5	22	42.5	L
50091-06-04RW	6	6	04	30	22	45.5
50091-08-05RW	8	8	05	33	24	50.5
50091-08-06RW	8	10	06	35.3	24	52.8
50091-10-05RW	10	8	05	33	23	49.5
50091-10-06RW	10	10	06	35.3	23	51.8
50091-12-06RW	12	10	06	35.3	25	53.8
50091-12-08RW	12	13	08	41	25	59
50091-15-06RW	15	10	06	35.3	25	53.8
50091-15-08RW	15	13	08	41	25	59
50091-18-08RW	18	13	08	41	26	60
50091-18-10RW	18	16	10	56	26	64.5
50091-22-10RW	22	16	10	56	28	66.5
50091-22-12RW	22	19	12	65.5	28	76
50091-22-16RW	22	25	16	76.7	28	81.5
50091-28-16RW	28	25	16	70.5	30	90.0
50091-35-20RW	35	32	20	93	36	100.5
50091-08-04RW	8	6	04	30	24	47.5	S
50091-10-04RW	10	6	04	30	26	49.5
50091-12-04RW	12	6	04	30	26	49.5
50091-12-05RW	12	8	05	33	26	52.5
50091-14-06RW	14	10	06	35.3	29	57.8
50091-14-08RW	14	13	08	41	29	63
50091-16-08RW	16	13	08	41	30	64
50091-16-10RW	16	16	10	56.5	30	68.5
50091-20-10RW	20	16	10	56	36	74.5
50091-20-12RW	20	19	12	65.5	36	84
50091-25-12RW	25	19	12	65.5	40	88
50091-25-16RW	25	25	16	76.7	40	93.5
50091-30-16RW	30	25	16	78	40	109.5
50091-30-20RW	30	32	20	91.5	44	108.5
50091-38-16RW	38	25	16	76.7	50	115.5
50091-38-20RW	38	32	20	91.5	50	114.5
Note:1. For use with braided hoses. 2. If use with spiral hoses, hose fitting series number is 50092-xx-xX.
